SALTEO - CARRÉ manufacturer of agricultural machinery

FRONT HOPPER

Multi-purpose front-mounted hopper for seeding and solid fertiliser distribution

The SALTEO front hopper can be coupled to seeding equipment, a strip-till or a hoe for fertilisation SALTEO fits onto the tractor perfectly with its compact hopper, with balanced distribution of the loads to ensure good handling and making it easy to drive when compacting soil ISOBUS SALTEO’s technology makes it easy to use.

Its stainless steel dosing unit ensures precision dosing for seeding and fertilising from 1.5Kg to 450 Kg/Ha.

See specifications

THE HOPPER

Dimension L=2m50 x l=1m70 x H=2m10
3 point front hitch category n°2
Flexible roll-up tarpaulin
Inside the hopper: Filter screen Bottom of hopper sensor

Hopper 1900L treated against corrosion
Integrated storage legs
Removable steps
Lights and signals

HOPPER: seeding and fertilising versions

	Capacity in Liters (L)	Weight (kg)
Seeding version	1900	600
Fertilising version	1900	600

THE METERING UNIT

ISOBUS control, compliant with 11783 standard
GPS-controlled, centralised, splined volumetric dosing unit
Integrated GPS speed information
Manometer to control the hydraulic pressure of the blowing.
Turbine speed sensor
Hydraulic blower drive (P+E+drain hose), hydraulic flow rate of 50L/min. required

St. steel distribution hose, 5m, to be attached on to the side of the tractor
St. steel dosing unit Ø114mm in seeding version and Ø154mm in fertilisation version. Flap for complete emptying of the dosing unit
Hopper isolation guillotine flap

THE EQUIPMENTS

FERTI KIT for INRO II strip till and ECONET hoe

Two choices of distribution head :

6-outlet distribution head with Ø114mm column, Ø65mm downpipes, vent, Ø45mm diffuser connection pipes

Distribution head from 7 to 16 outlets with Ø154mm column, Ø65mm downpipes, vent, Ø45mm diffuser connection pipes

THE OPTIONS

THE ADVANTAGE OF THE TOUCH800® TERMINAL OPTION

If the tractor is not equipped with the ISOBUS system, the TOUCH800® universal terminal can be used on all machines that meet the requirements of ISOBUS standard 11783.

8’’ anti-glare touch screen
Complies with the AEF certified ISOBUS 11783 standard
High resolution for simultaneous display of main and auxiliary information
Displays advance speed, instantaneous flow rate, surface area covered, turbine speed, hopper level.

Pair of mirrors

Venturi kit for seeding version

Venturi kit for fertilising version
